Kohler SDMO Automatic Transfer Switch IP20 (200-630A)

Categories:

VERSO 200

Ratings (A):  200, 250, 400 & 630A

Type: Three phase

Frequency: 50-60 Hz

Voltage Range: 208/220/230/240v & 380/400/415/440 V

Configuration: Auto-Configuration of Voltage/Frequency Min/Max & Configurable Thresholds

Display & Setting: By LCD, Supplied with Manually Operated Key – Can be Padlocked in Manual Mode

Voltage Drop Tolerated: 30% of the Nominal Voltage @400V

Maximum Voltage Tolerated by the Equipment: 332 V

Protects Against a Change in the Phase Rotation Direction: YES

Lightning Arrestor: OPTIONAL

Confirmation of Mains Return: YES (Configurable)

Protection Index: IP20 (IP55 on Request)

Inputs/Outputs: 3 Configurable Dry Contact Inputs/2 Configurable Relay Outputs

Dimensions (H x W x D): 840 x 640 x 450 mm (IP55: 1750 x 700 x 500 mm)

Specifications

ATS Amp Rating

200-630A
ATS IP Rating

IP20, IP55
Enquire
Now Available

Description

SDMO CHANGE OVER SWITCHES ARE PERFECTLY SUITED TO ALL POWER FAILURE SITUATIONS
Thanks to its expertise and knowledge in the energy business, SDMO offers a wide range of automatic changeover switches. SDMO Industries is able to meet all your requirements and adapt to each of your needs.

CHANGE OVER SWITCHES VERSO 200
The Verso 200 is an automatic changeover switch intended for larger installations. This version is available from 200 to 630A in an IP20 metal control unit (IP55 on request)

Additional information

ATS Amp Rating

200-630A
ATS IP Rating

IP20, IP55

VERSO 200

Ratings (A):  200, 250, 400 & 630A

Type: Three phase

Frequency: 50-60 Hz

Voltage Range: 208/220/230/240v & 380/400/415/440 V

Configuration: Auto-Configuration of Voltage/Frequency Min/Max & Configurable Thresholds

Display & Setting: By LCD, Supplied with Manually Operated Key – Can be Padlocked in Manual Mode

Voltage Drop Tolerated: 30% of the Nominal Voltage @400V

Maximum Voltage Tolerated by the Equipment: 332 V

Protects Against a Change in the Phase Rotation Direction: YES

Lightning Arrestor: OPTIONAL

Confirmation of Mains Return: YES (Configurable)

Protection Index: IP20 (IP55 on Request)

Inputs/Outputs: 3 Configurable Dry Contact Inputs/2 Configurable Relay Outputs

Dimensions (H x W x D): 840 x 640 x 450 mm (IP55: 1750 x 700 x 500 mm)

Verso 200 Operating Guide

Automatic Transfer Switches Brochure
